厂商名称： 日本安立ANRITSU

手持式矢量网络分析仪VNA Master MS2024A/MS2026A

频率范围： 2MHz to 4GHz(MS2024A)/2MHz to 6GHz(MS2026A)

MS2024A网络分析仪MS2024A资料功能特点：

• S 参数测量菜单 S11/S21 幅度显示， S11/S21 相位显示， S11 圆图显示， S11 驻波比显示及时域故障点显示

• 现场应用测量菜单 回波损耗， VSWR ，插入损耗， DTF 故障点定位 RL/VSWR ， 2 端口增益， 1 端口相位， 2 端口相位， Smith 圆图显示

• 对于两端口测量提供可选输出功率模式

• 扫描速度 提供满足要求的频率扫描速度及 DTF 时域测量速度

• RF 射频干扰抑止能力

• 内置式 Bias Tee 偏置电压

• 较轻的重量（ <6.4 盎司，包括电池）

• 可更换充电电池 内置锂电池提供 3 个小时的测量续航能力

• 多标记模式 支持同时显示 6 标记，每个标记均提供差值标记模式，便于进行响应对比参数测量

• 信号标准及电缆标准编辑

• 内置 8 种语言显示模式

• 大容量存储及数据转换能力

内部存储器可以实现 1000 条曲线的存储容量，可以通过以太网接口，存储卡或 USB 接口进行数据传输

​

MS2024A网络分析仪MS2024A资料概述

VNA Master MS2024A is a handheld Vector Network Analyzer designed to make accurate vector corrected 1-port magnitude, phase, and Distance-To-Fault measurements and 1-path 2-port magnitude and phase measurements from 2 MHz to 4 GHz.

For field engineers and technicians supporting aerospace & defense platforms, commercial wireless backhaul, and other general purpose applications, the VNA Master are the first and only truly portable handheld 2-port Vector Network Analyzers (MS2024A/26A) offering 2 MHz to 6 GHz frequency coverage for precisely detecting faults in RF cables, connectors, and antennas anytime, anywhere.

VNA Master is also an excellent solution for low-cost manufacturing and other general purpose applications given the broad frequency coverage, excellent performance, and integrated capabilities.

MS2024A网络分析仪MS2024A资料特征

• Vector Network Analysis from 2 MHz to 4 GHz
• Vector Voltmeter replacement
• 2 ms/data points sweep speed
• USB/Ethernet for data transfer
• Store 1000 traces and setups in internal memory
• Memory card slot for data storage and transfer
• High resolution daylight viewable TFT color display
• Built-in and custom editable Cable and Signal Standard List
• Local Languages: English, Spanish, Italian, French, German, Japanese, Korean, and Chinese.
• Automate repetitive tasks with remote programming via Ethernet connector
• Weight < 6.4 lbs (2.9 kg)
• Master Software Tools for trace analysis, editing, reporting, and much more
