MM1-1044LCH-2
The MM1-1044L is a low power GaAs MMIC double balanced mixer that is designed for and operates at the K and Ka band 5G frequencies. MM1-1044L is a low power Ka band mixer that works well as both an up and down converter. This mixer offers low conversion loss and high LO to RF isolations over a broadband Ku to Ka band. The sister MM1-1044H is recommended for high linearity applications. The MM1-1044L is available as both wire bondable die and as connectorized modules. For a list of recommended LO driver amps for all mixers and IQ mixers, see here.
MM1-1044LCH-2 1.2 Features ▪ Low +7 dBm minimum input drive ▪ Low cost Ka band mixer ▪ Small 0.77mm x 1.17mm form factor ▪ 5G band coverage
MM1-1044LCH-2 1.3 Applications ▪ Mobile test and measurement equipment ▪ Power efficient modules ▪ 5G transceivers
